24v Non Dimmable Driver IP67

Output Power (click for spec sheets)	12W	20W	30W	45W	60W	100W	150W	200W	240W	350W	600W
Output Voltage	24V	24V	24V	24V	24V	24V	24V	24V	24V	24V	24V
Output Rated Current	0.5A	0.83A	1.25A	1.88A	2.5A	4.2A	6.25A	8.3A	10A	14.6A	25A
Input Voltage Range	170 - 265V	170 - 265V	170 - 265V	170 - 265V	200 - 240V	200 - 240V	200 - 240V	200 - 240V	200 - 240V	200 - 240V	90 - 305VAC
Input AC Frequency	50 - 60Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz	47 - 63Hz
Power Factor	>0.55	>0.55	>0.55	>0.55	>0.65	>0.65	>0.65	>0.65	>0.98	>0.98
Efficiency	>81%	>83%	>83%	>83%	>90%	>91%	>92%	>92%	>92%	>92%	>95%
Input AC Current	0.1A	0.18A	0.25A	0.35A
Inrush Current					60A	70A	70A	70A	70A	70A	70A
Dimensions (mm) L x W x H	60 x 30 x 20	148 x 30 x 20	148 x 30 x 20	167 x 30 x 20	148 x 40 x 32	162 x 40 x 32	190 x 52 x 37	190 x 63 x 38	193.6 x 66.2 x 40	234 x 73 x 39	280 x 144 x 48.5

Wattage	12W, 20W, 30W, 45W, 60W, 100W, 150W, 200W, 240W, 350W, 600W
Voltage	24V
IP rating	IP67
Dimmable	Non-dimmable
Warranty	3 Year Standard and 5 Year Extended Manufacturers Warranty
